GZY-76
UHF RFID Desktop Reader
This is a professional desktop RFID card issuing machine, specially designed for input tag information efficiently. It features intelligent automatic entry function, which can quickly bind tags with data, reducing manual operations. Compact and portable, powered by USB, with stable and reliable reading and writing performance, it significantly improves work efficiency. It also supports dual USB communication and multiple working modes, and can be widely applied in RFID fields such as warehousing
/
USB RFID Desktop Reader/Writer
Features
-
Automatic Tag-Data Binding -
Multi-Platform SDK -
Superior Protection -
Dual USB-Lightweight Design -
Prevent Cloning -
Multi-Mode Communication
Specifications
-
RFID Performance
Air interface ISO-18000-6B、ISO-18000-6C（EPC G2） Frequency range 865-868, 902-928MHZ（customized）
Antenna type Near-field antenna
Polarization mode Circular polarization
Communication interface USB
Application software Provide with DLL, support secondary development
Read distance 0~150mm
Write distance 0~100mm
-
Physical Performance
Dimension 119(L)*104 (W)*28(H)mm
Fuselage material ABS + Aluminum alloy
Weight 150 g
Humidity 5% to 95%, non-condensing
Protection grade IEC IP52
Operation temperature -20 ºC to +60 ºC
Storage temperature -40 ºC to 80 ºC
Heat dissipation Air cooled
Applications
