GZY-122
UHF RFID Handheld Reder
It is a powerful industrial handheld device that integrates multiple technologies such as UHF RFID, barcodes, low frequency, high frequency and facial recognition. It is equipped with an 8-core 2.0GHz high-speed processor, 4GB RAM, 64GB ROM and Android 12.0 system. Its performance is extremely stable and is widely used in RFID fields such as warehousing and logistics, asset management, inspection and industrial manufacturing.
/
1-2M Android RFID Handheld Reder
Features
-
Impinj E710 -
5.72-inch IPS High-Definition Screen -
RAM+ROM: 3/4/6 GB +32/64/128 GB -
4300/6700mAh Host Battery -
MTK 6762-8-Core @ 2.0GHz
-
Host IP65/1.5m Drop Resistance
Specifications
-
PHYSICAL CHARACTERISTICS
Dimension 170.8mm(H)x81mm(W)x28.6mm(D)±2 mm Net Weight 400g (including battery&wrist strap) Display Tough 5.5 in. TFT-LCD(720x1440)touch screen with backlight Backlight LED backlight Expansions 2 PSAM; 2 SIM, 1 TF Battery Rechargeable li-ion polymer, 3.8V, 5200mAh COLOR CAMERA Resolution Rear 13 megapixel, front 5.0 megapixel
COLOR CAMERA Lens Auto-focus with LED flash
-
RFID UHF READER
Frequency 860-865Mhz /902-928Mhz（Can be customized） Protocol EPC C1 GEN2/ISO 18000-6C Antenna Gain Circular antenna(2dBi) R/W Range 2m(depends on rfid tags performance) RF output 0-33dBm adjustable Communication method Bluetooth, 4g, wifi 2D CMOS Imager OPTIONAL 2D barcode Symbologies PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode, Postal Codes, US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal. etc. -
PERFORMANCE CHARACTERSTICS
CPU Cortex A73 2.0GHz octa-core
Operating System Android 10.0
Memory RAM：3GB; ROM:32GB;（optional）RAM：4GB ROM：64GB
MicroSD(max 256GB expansion) -
DEVELOPMENT ENVIRONMENT
SDK Software Development Kit
Language Java
Environment Android Studio or Eclipse
-
USER ENVIRONMENT
Operating /Storage Temp -20℃to 50℃/-20℃to 70℃ Humidity 5%RH to 95%RH(non-condensing)
Drop Spec. 5ft./1.5 m drop to concrete across the operating temperature range Dust & Water Proof. IP65, IEC compliance ESD 15kv air discharge, ±8kv direct discharge
