GZY-31
Integrated USB RFID UHF Reader
The GZY-31 ultra-high frequency desktop RFID tag reader features a 255×200mm ultra-thin design (weighing only 1kg). Its near-field antenna enables precise group reading of up to 50 tags per second within a range of 300mm. The aluminum and tempered glass body is protected by IP54, and it connects directly via USB-TypeC without the need for drivers. It can output inventory data with a single keystroke on a simulated keyboard, making it suitable for space-constrained scenarios such as tool cabinets
/
USB RFID Desktop Reader/Writer
Features
-
50 Tags/Sec in Near-Field -
Ultra-Thin 255mm -
Lightweight 1kg -
Emulated keyboard, no programming -
IP54 -
Operating Temperature: -20℃ to 65℃
Specifications
-
RFID Performance
Air interface ISO-18000-6B、ISO-18000-6C（EPC G2） Frequency range 865-868, 902-928MHZ（customized）
Antenna type Near-field antenna
Polarization mode Circular polarization
Communication interface USB
Application software Provide with DLL, support secondary development
Read distance 0~300mm
Write distance 0~100mm
Chip E310 -
Physical Performance
Dimension 119(L)*104 (W)*28(H)mm
Fuselage material ABS + Aluminum alloy
Weight 150 g
Humidity 5% to 95%, non-condensing
Protection grade IEC IP52
Operation temperature -20 ºC to +60 ºC
Storage temperature -40 ºC to 80 ºC
Heat dissipation Air cooled
Applications
