GZY-X2020
HARD LAUNDRY TAG / BOTTON TAG
Square washing label, size 20×20mm, with a built-in high-temperature resistant chip, installed by sewing into a bag. The farthest reading distance is 40 centimeters. The structure is compact and can withstand 180℃ drying and high-temperature sterilization. It is specifically designed for the management of light and small linen items such as underwear and bed sheets that are frequently washed.
/
Micro anti - metal RFID tag
Features
-
Compact 20mm Round Size -
110℃ High Temperature Resistance -
200 Wash Cycles Endurance -
135℃ High-Temperature Sterilization -
Cloth Pocket Insert Installation -
50+ Years Data Retention
Specifications
-
Physical Features
Model GZY-X2020
Size 20( Dia) x 2.3 ( H) mm
Material PPS
Working Temp -25~+110℃
Storage Temp -40~+85℃
Installation Methods sewing Package details 500Pcs/bags
Weight 2g
Chemicals Normal common chemicals in the washing processes
Colour Black -
RFID Features
Protoccol Standard EPC CLASS1 GEN2, ISO 18000-6C
Working Frequency 865-868Mhz, 902-928Mhz(Customized)
Chip Type NXP Ucode 7, Ucode8; M730
EPC Memory 96-128bit, TID:64bit
Read distance 0.1-0.4m (depend on reader performance) Re-Write >100,000times
Data Storage >10 years
Estimated Lifetime 200 washing cycles or 2 years -
Others Features
Application *Management of uniforms；
*Medical apparel management；
*Military clothing management；
*Personnel patrol management.IP Rating IP68
