GZY-R4025
Flexible on-metal RFID tag
Size: 40×25mm, thickness: only 0.75mm. It is a thin model, flexible and easy to adhere. The farthest reading distance on the metal surface is 2.5 meters. The performance has significantly improved, making it suitable for metal asset identification where a longer reading distance is required and strict thickness standards are imposed.
/
Micro anti - metal RFID tag
Features
-
Ultra-Thin 0.75mm Thickness -
2.5 Meters -
Support mainstream industrial printers -
Multi-Model Compatible(Customized) -
85°C/85% RH high-temperature & humidity test -
Printable White Surface, Clear
Specifications
-
Physical Features
Model GZY-R4025 Size 40(L) x 25(W)x 0.75(H)mm
Material PET/Aluminum Foil/Foam
Working Temp -40~+85℃
Storage Temp -40~+120℃
Installation Methods 3M Adhesive
Package details 500pcs Per roll/Small box,2000pcs/Carton
Weight 0.85kg/Reel
Colour White -
RFID Features
Protoccol Standard EPC CLASS1 GEN2, ISO 18000-6C
Working Frequency 865-868Mhz, 902-928Mhz(Customized)
Chip Type NXP Ucode 8, 9，Impinj M730
EPC Memory 96-128bit, TID:64bit
Read distance 1-7m, On Metal Surfaces (depend on reader performance)
Re-Write >100,000times
Data Storage >10 years
-
Others Features
Application ● IT Asset Management
● Production line Management
● Medical Equipment Management
● Fixed Asset Management
optional Customization Surface laser, printing LOGO, serial number, Encoding, etc
IP Rating IP68
Support Printer Postek TX3r, SATO CL4NX, Zebra ZT410, etc.
