GZY-610
Modbus UHF RFID Reader for Automation
It is a sturdy and durable device specially designed for harsh industrial environments. It supports the Modbus RTU protocol and offers continuous, command and trigger working modes, as well as cache, timing and real-time data reporting functions.It provides real-time status indication through LEDs and buzzers.It is widely used in RFID scenarios such as intelligent warehousing and industrial production lines.
/
Modbus UHF RFID Reader for Automation
Features
-
24/7 Continuous Operation -
ISO18000-6B/6C -
IP65 -
Mode: Auto, Trigger, and Interactive -
10-Meter for Vehicles/Logistics -
TCP/IP, RS485, and Wiegand
Specifications
-
RFID Performance
RFID Frequency 860-865Mhz /902-928Mhz（Can be customized） Air Interface Protocol EPC global UHF Class 1 Gen 2 / ISO 18000-6C Reader Chip IMPINJ R2000 / E710 / TM600 RF output 13 – 27 dBm（adjustable）adjustable 4dbi antenna built-in
Reading Distance 300 - 1000mm(depens on tags performance) Communication interface TCP/IP、RS232、RS485、Wiegand26/34 interface Application software interface Provide API development kit and application routines Support RSSI Support Antenna Parameters 3dBi Circularly Polarized Antenna (built-in)
Way of Working Automatic mode, trigger mode, interactive mode, etc. Input/Output (GPIO) 2-way input, 2-way output (optional) Output Power Accuracy +/- 1dB
Input Power Accuracy +/- 0.2dB Receiving Sensitivity < -85 dBm
-
Physical Performance
Dimensions 90mm(L) x 94mm(W) x40mm(H) Power supply With 220V AC input, the output of +12 V/3A DC power converter Metrial ABS + aluminum alloy
Weight 1.5 Kg Humidity 5% to 95%, non-condensing Protection class IP67 Working temp -20℃ to +70℃ Storage temp -30℃ to +85℃ Heat dissipation method Air cooling
Applications
