GZY-R5025
Soft flexible RFID on-metal label
Size: 50×25mm. Maintains flexible printing characteristics and a thickness of 1.25mm. The farthest reading distance on the metal surface is 4.0 meters. The performance is balanced and it supports customized surface information. It is suitable for various metal containers and equipment assets for medium and long distance identification and management.
/
Micro anti - metal RFID tag
Features
-
50x25mm -
Metal Surface: 4.0 Meters -
Resistant to Alcohol and Gasoline -
Rewrite Cycles ≥100,000 -
Supports Custom Printing Content -
Roll Packaging for Easy Labeling
Specifications
-
Physical Features
Model GZY-R5025 Size 50(L) x 25(W)x 1.25(H)mm
Material PET/Aluminum Foil/Foam
Working Temp -40~+85℃
Storage Temp -40~+120℃
Installation Methods 3M Adhesive
Package details 500pcs Per roll/Small box,2000pcs/Carton
Weight 0.85kg/Reel
Colour White -
RFID Features
Protoccol Standard EPC CLASS1 GEN2, ISO 18000-6C
Working Frequency 865-868Mhz, 902-928Mhz(Customized)
Chip Type NXP Ucode 8, 9，Impinj M730
EPC Memory 96-128bit, TID:64bit
Read distance 1-4m, On Metal Surfaces (depend on reader performance)
Re-Write >100,000times
Data Storage >10 years
-
Others Features
Application ● IT Asset Management
● Production line Management
● Medical Equipment Management
● Fixed Asset Management
optional Customization Surface laser, printing LOGO, serial number, Encoding, etc
IP Rating IP68
Support Printer Postek TX3r, SATO CL4NX, Zebra ZT410, etc.
