In the realm of industrial IoT and asset tracking, minimizing the footprint of RFID tags while maintaining performance on metal surfaces is a significant engineering challenge. We are proud to introduce the GZY-R1808, a revolutionary flexible RFID on-metal tag designed to solve interference issues in compact metal environments.

1、Compact Design for Critical Assets

The GZY-R1808 is engineered for assets where surface area is limited. With dimensions of just 18 × 08 mm and an ultra-thin profile of 1.23 mm, this tag is arguably one of the smallest flexible on-metal solutions in the market. It is the ideal choice for tracking IT assets (servers, switches), small metal tools, and industrial molds where traditional hard tags are too bulky.

2、Exceptional RF Performance

Despite its miniature size, the GZY-R1808 delivers robust performance powered by the UCODE 9 chip.

Read Range: It achieves a theoretical read range of 0.8 meters on metal surfaces (FCC 902-928MHz).

Flexibility: Its flexible construction allows it to mount securely on curved metal surfaces, ensuring consistent readability regardless of the asset's shape.

3、Built for Harsh Industrial Environments

Reliability is paramount in industrial applications. The GZY-R1808 is tested to withstand extreme conditions:

Waterproof: Rated IP68, capable of withstanding immersion in 1 meter of water for 5 hours.

Chemical Resistance: The tag maintains functionality after wiping tests with 95% Alcohol and No. 92 Gasoline.

Heat & Humidity: Successfully passed the "Double 85" test (+85°C  85% 148 hours).

4、Compatibility and Customization

The GZY-R1808 supports on-site printing and encoding, offering flexibility for dynamic asset management. It is compatible with major industrial RFID printers such as the SATO CL4NX and Zebra ZT410, allowing for the customization of Logos, Barcodes, and QR codes directly onto the tag.

5、Technical Specifications
